Hema HX-2 Wi-Fi Reversing Camera

SKU: 9321438002475 Learn More»
Hema HX-2 Wi-Fi Reversing Camera
Free Shipping
$185
$199

FREE SHIPPING

This item is sent via Express Courier. All freight is fully insured.

In stock, dispatch 1 - 2 days Express Shipping Price Match Guarantee Customer Reviews

Product Description

Hema HX-2 Wi-Fi Reversing Camera, 1 Year Warranty. Hema's Wi-Fi reversing camera used in conjunction with the Hema HX-2 Navigator offers enhanced rearward visibility for drivers and, thus, help minimise the risk of "blind zone" accidents whenever your vehicle is moving in reverse.

This wireless backup camera helps you easily spot vehicles, pedestrians, pets and other hard-to-see obstructions behind your vehicle.

Suitable for both 12v and 24v vehicles (camera and transmitter are compatible from 9 to 28 Volts).

Key Features

  • COMPATIBILITY - Works seamlessly with Hema HX-2 Naviagtor
  • WIDE FIELD OF VIEW - 160-degree wide-angle field of view; shows what’s behind your vehicle when in reverse
  • BUILT-IN WI-FI - Built-in Wi-Fi® connectivity transmits live camera view from the reversing camera directly to your HX-2 navigator’s display
  • WIRELESS RANGE - Transmits camera footage up to 28M away (range varies based on installation)

 Specifications:

Receive

Wifi
Power ON
Latency
Resolution

Android OS
1.0 S
120ms
VGA

Function Frame Rate
Video Codec
Video in System
Video Output
Impedance
30f/s
MPEG4
PAL
75Ω, Typ

Video Characteristics Video Output
Levl
S/N
Operation
Frequency
RF Impedance
1.2 Vp-p, Typ.

50dB,Min
2412~
2483.5MHz
(WIFI 802.11 g/n)
50Ω, Typ

RF Specification Receiving
Sensitivity
Output Power
RF Bit Rate
Modulation
Channel
-89dBm

12dBM
11Mbps
QPSK, 16QAM
CH1 to CH13
DC Power Supply

Operating Temperature
DC 9 -
16V/200mA
-20°c~70°c
Enronmental Specification

Storing Temperature
Operating  Humidity

-30°c~85°c
Humidity 90°c
Others

Unit Dimensions (mm)
Unit Weight

45 x 48 x 15.6mm
50.00 grams

Note: Initial install of reversing camera needs to be wired by a qualified auto electrician. Following install, the camera operates via Wi-Fi. Wi-fi signal performance can be impacted by obstructions. This device is designed specifically for vehicle use and performance with camper trailers/caravans may vary.

Specifications

SKU 9321438002475

Brand Hema

GTIN 9321438002475

Warranty Period: 1 Year

Product Category Reversing Camera

Dimensions 45 x 48 x 15.6mm

Weight (kg) 0.5000
