Victron BlueSolar MPPT Charge Controller 150/45
SKU: SCC115045222 Learn More»
FREE SHIPPING
This item is sent via Express Courier. All freight is fully insured.
Accessories
Product Description
Victron BlueSolar MPPT Charge Controller 150/45, 5 Year Warranty. A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, BlueSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. BlueSolar maintains battery health, extending its life.
Ultra Fast Maximum Power Point Tracking
By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.
Remote Monitoring and Control
Remotely control and monitor the extensive features of your BlueSolar MPPT charger by attaching a Bluetooth dongle and pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet with a GX device, the Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both VictronConnect and VRM are free to use. For remote installations - even when there is no internet connection nearby - you may be able to monitor your MPPT by connecting the GlobalLink 520.
Â
Specifications
SKU SCC115045222
Brand Victron
GTIN 8719076053033
Warranty Period: 5 Years
Product Category Solar Charge Controllers
Charge Current (A) 45
Voltage 12 / 24 / 48V Auto Select (software tool needed to select 36V)
Dimensions 130mm x 186mm x 70 mm (h x w x d)
Amps 45
Humidity 95%, non-condensing
Protection PV reverse polarity, Output short circuit, Over temperature
Operating temperature range -30 to +60°C (full rated output up to 40°C)
Float Default setting: 13,8 / 27,6 / 41,4 / 55,2V (adjustable)
Efficiency Max. 98%
Charge voltage 'absorption' Default setting: 14,4 / 28,8 / 43,2 / 57,6V (adjustable)
Temperature Compensation -16 mV / -32 mV / -64 mV / °C
Nominal PV Power 12V: 650W / 24V: 1300W / 36V: 1500W / 48V: 2600W
Net Weight (kg) 1.25
