Victron MultiPlus-II Inverter Charger 24/3000/70-32 230V GX
SKU: PMP242306000 Learn More»
FREE SHIPPING
This item is sent via Express Courier. All freight is fully insured.
Accessories
Learn More»
Product Description
Victron MultiPlus-II Inverter Charger 24/3000/70-32 230V GX, 5 Year Warranty. An Inverter/Charger with device networking built-in, the MultiPlus-II GX communicates with a solar charger, batteries, and other devices to control a grid-connected, off-grid, or remote power installation. Capable of parallel operation for increased power output, or battery charge-rates, the MultiPlus-II GX can also be configured for three-phase supply. A host of advanced features - such as uninterrupted power supply, setting load limits, and supplementing limited grid-power availability with battery power - can all be controlled straight from your phone or smart device. Remote monitoring is also possible.
Specifications
SKU PMP242306000
Brand Victron
GTIN 8719076051695
Warranty Period: 5 Years
Product Category Power Inverter Chargers
Output Current Rating (Amps) 70
Model MultiPlus 24/3000/70
Product Type MultiPlus Inverter/Charger
Wattage (W) 3000
Charge voltage 'storage' 26.4V
Output Voltage and Frequency 230VAC ± 2% / 50Hz ± 0,1% (1)
Input Voltage 19 – 33V
Product Dimensions (mm) LxWxH 506mm x 275mm x 147mm
Net Weight (kg) 19
Inverter Output Continuous Watts 2400W (continuous output power at 25°C)
Charge voltage 'absorption' 28.8V
Peak power 9000W
Operating temperature range -40 to +65°C (fan assisted cooling)
No load power consumption 9W | 3W in search mode
AC Input 187-265 VAC | 45 – 65 Hz
Charge Voltage Float - Wet (25 degrees)** 27.6V
Output Power 2400W (continuous output power at 25°C) | 2200W (continuous output power at 40°C) | 1700W (continuous output power at 65°C)
NOTE For further specifications and performance details, please download the PRODUCT CARD under our Product Details tab
Inverter Output Nominal Efficiency 94% (maximum)
Videos
Did You Know - Changing the logo on a GX device
Did You Know - You can update a MultiPlus Firmware using an Android Phone?
How to set up BMV Battery Monitor for lead and lithium batteries
Product Q&A
-
Can I use non Bluetti branded solar panels with my Bluetti Lithium Power Station?
Yes, provided your solar panel/s have MC4 Connectors which will attach to the Bluetti Power Station. If your solar panel has an Anderson connector, you will need to buy an Anderson to MC4 charging cable. Please also note that each power station will have a maximum open circuit voltage.
-
Can these chargers take solar input?
No, the battery charging component is an AC input, meaning only AC power (mains power) can charge through this unit.
-
What size Generator can I use with the Multiplus Inverter Chargers?
The below generators are the minimum recommend sizes based on an AVR generator:
Inverter Charger Size Minimum Recommended Generator Size 240V AC Input Current Limit 800VA 2 kVa 5A 1200VA 2.5 kVa 7A 1600VA 3 kVa 10A 3000VA 5 kVa 16A 5000VA 8 kVa 25A If your generator is smaller than the recommended size for your inverter/charger, you will definitely need to adjust the settings on the inverter/charger and reduce the AC input current limit, and/or a DC charge current limit to prevent overloading the generator. If you do want an inverter based generator get one that is at least 30% larger than required than an equivalent AVR based model to help prevent overloads.
