Victron MultiPlus-II Inverter Charger 24/3000/70-32 230V

SKU: PMP242305010 Learn More»

Free Shipping

FREE SHIPPING

This item is sent via Express Courier. All freight is fully insured.

Accessories

Victron Single Phase AC Current Sensor, Max 40A

$92

Victron Current Transformer 100A:50mA for MultiPlus-II (1m) Wire-end

$65

Victron Current Transformer 100A:50mA for MultiPlus-II (5m) Wire-end

$74

Victron Current Transformer 100A:50mA for MultiPlus-II (20m) Wire-end

$129

Click '+' to show more accessories

Call 1300 400 122

Add To Wishlist

Learn More»

Customer Reviews

"Great quality product"

Matthew Bond

Product is as advertise and can't go past the victron brand.

(Posted on 3 July 2022)

"Great product great service"

Ian Sandlant

I brought the Multiplus II and other products over the years from my generator. The website is super easy to use, I have always received exactly what was offered (no surprises) at a good price. The Victron Multiplus II is a high quality solar off grid product, very easy to install and was operating

(Posted on 19 September 2020)

Go to: Product Details

Go to: Specifications

Product Description

Victron Multiplus-II Inverter Charger 24V / 3000VA / 70A Battery Charger with 32A AC Transfer Switch, 5 Year Warranty. The MultiPlus-II combines the functions of the MultiPlus and the MultiGrid. It has all the features of the MultiPlus, plus an external current transformer option to implement PowerControl and PowerAssist and to optimize self-consumption with external current sensing (max. 32A). It also has all the features of the MultiGrid with built-in anti-islanding and an increasingly long list of country approvals.

PowerAssist:

The MultiPlus-II will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery.

ESS: Energy Storage Systems:

The MultiPlus-II is the key component in a Victron ESS system, providing the flexibility to combine with MPPT Solar Chargers or Grid-tie PV Inverters. For examples and more detailed information see the ESS (Energy Storage System) manual.

Uninterrupted AC power (UPS function):
In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.

Remote Monitoring and Control:
Monitor and control your Multi and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your Multi to auto-starting a back generator and more...

Please Note: The image shown is not the correct image for this model.

Go to: Product Details

Go to: Videos

Specifications

SKU PMP242305010

Brand Victron

GTIN 8719076048084

Warranty Period: 5 Years

Product Category Power Inverter Chargers

Output Current Rating (Amps) 70

Model MultiPlus 24/3000/70-32

Product Type Inverter and charger in one package

Wattage (W) 2400

Charge voltage 'storage' 26.4V

Output Voltage and Frequency 230 Vac ± 2% / 50 Hz ± 0.1%

Input Voltage 19 - 33V

Product Dimensions (mm) LxWxH 147 x 275 x 506

Net Weight (kg) 18

Inverter Output Continuous Watts 2400W (continuous output power at 25°C)

Charge voltage 'absorption' 28.8V

Peak power 5500W

Operating temperature range -40 to +65°C (fan assisted cooling)

No load power consumption 13W | 3W in search mode

AC Input 187 - 265 VAC | 45 - 65 Hz

Charge Voltage Float - Wet (25 degrees)** 27.6V

Output Power 2400W (continuous output power at 25°C) | 2200W (continuous output power at 40°C) | 1700W (continuous output power at 65°C)

NOTE For further specifications and performance details, please download the PRODUCT CARD under our Product Details tab

Inverter Output Nominal Efficiency 94% (maximum)

Go to: Specifications

Go to: Q & A

Videos

MultiPlus-II introduction

Go to: Videos

Go to: Reviews

Product Q&A

Ask Us a Question

Can these chargers take solar input?

No, the battery charging component is an AC input, meaning only AC power (mains power) can charge through this unit.

What size Generator can I use with the Multiplus Inverter Chargers?

The below generators are the minimum recommend sizes based on an AVR generator:

Inverter Charger Size	Minimum Recommended Generator Size	240V AC Input Current Limit
800VA	2 kVa	5A
1200VA	2.5 kVa	7A
1600VA	3 kVa	10A
3000VA	5 kVa	16A
5000VA	8 kVa	25A

If your generator is smaller than the recommended size for your inverter/charger, you will definitely need to adjust the settings on the inverter/charger and reduce the AC input current limit, and/or a DC charge current limit to prevent overloading the generator. If you do want an inverter based generator get one that is at least 30% larger than required than an equivalent AVR based model to help prevent overloads.

Go to: Q & A

Go to: Warranty

Customer Reviews

Write a product review

Great quality product Review by Matthew Bond

Product is as advertise and can't go past the victron brand.
(Posted on 3 July 2022)

Great product great service Review by Ian Sandlant

I brought the Multiplus II and other products over the years from my generator. The website is super easy to use, I have always received exactly what was offered (no surprises) at a good price. The Victron Multiplus II is a high quality solar off grid product, very easy to install and was operating within the hour.
(Posted on 19 September 2020)
